Midi-Lite – Specifications


Side mounted only
Machine width (m) 3.700
Machine length (m) 1.700
Machine head height (m) 1.100
Bale guard height (m) N/A
Machine body length (m) 3.015
Raised head height (m) 2.200
Maximum bale width (m) 1.360
Maximum bale length (m) 2.600
Maximum bale height /diameter (m) 1.000
Machine weight (kg) 790
Maximum bale weight 400
Machine + bale weight (kg) 1,190
Round bale diameter (m) 1.0
Rectangular bale sections/wafers (m) 1.2 x 1.0
Oil flow (l/min) 55
Distance thrown (m) 12 – 15

Key Information

  • First self-loading spreader for 1t loaders
  • One horizontal rotor for reduced weight and straight line spread pattern
  • Lightest machine available and suited for the tractor fore end loaders, Skidsteer and Hof
  • Head can be raised to reduce overall width to 3m
  • Spreads up to 14m


  • Fast operation, approximately one minute to load and de-twine followed by less than one minute to discharge and spread
  • Only one loader required, no second tractor and pneumatic spreader tied-up
  • Proven design for over 20 years
  • Truly self loading from the stack and floor
  • Versatile, enables loading and spreading of round and rectangular bales
  • No electrics; only one, double acting two-way spool required and no low pressure return line

Spread Pattern
